Features

*Support IEEE802.11b/g/n wireless and wired network standard

*Support mobile phones and tablet PCs with android and Apple system

*Support 32G TF card

*HD 1.3 Mega Pixels CMOS image sensor

*Support full-duplex voice intercom

*Support free P2P cloud record alarm information

*Support human body PIR sensor theft alarm

*Support tamper alarm

*Support five users simultaneously monitor

*HD 720P video picture quality

1: TF card socket

2: Tamper alarm switch

3: 12V power connector, packaging adapter power cable, according to the correct polarity, put the cable to terminal. The above picture adapter cord for reference, in accordance with the direction of the terminal hole actual installation. Power polarity as shown above.

4: RJ45 network cable interface

5: Reset button, if a customer forgot security password, after the boot holding down the button for above 5 seconds, automatically revert to the factory settings. You need to remove the device before, then re-add the new device at the APP.

6: Equipped with wired network cable to connect routers.

1: Use four screws at the corner to fix rain cover on the wall or wooden board, then put product into the rain cover and fixed with a screw.Power cord and network cable can be inserted through holes, which open in the middle and at the bottom of the rain cover.

2: Use two screws in the middle to fix rain cover to the 86 box (Product packaging does not include the two screw), then put product into the rain cover and fixed with a screw. Power cord and network cable can be inserted through holes, which open in the middle and at the bottom of the rain cover.

3: Use double-sided adhesive tapes stuck in the rain cover, then firmly fixed to the wall or wooden board. Finally, put product into the rain cover and fixed with a screw. Power cord and network cable can be inserted through holes, which open in the middle and at the bottom of the rain cover.
